7
[2] [Controller Setup]
Reconnect: Reconnect the axes.
If the software connects to multiple controllers linked by controller link cables, always select
Reconnect after turning off and then on again the power to a connected controller to which the
teaching pendant is not connected directly.
Assign Axis Number: Set the axis number for an integrated controller. This menu item does not do
anything for a separate controller.
Reset Software: Reset (restart) the software.
* This menu item is available only when the controller supports the software reset function.
Refer to “Supported Models.”
(6) Window
[1] [Cascade]
Rearrange all open windows in such a way that they are cascaded (staggered) on top of each other.
[2] [Tile
Vertical]
Rearranges all open windows as vertical tiles.
[3] [Tile
Horizontal]
Rearranges all open windows as horizontal tiles.
[4] [Arrange
Icons]
Arrange all window icons (minimized windows).
[5] [Minimize
All]
Minimize all open windows.
[6] [Maximize
All]
Restore all window icons (minimized windows) to their original size.
[7] [Tree
View]
Show/hide the tree view (Fig. 3.4).
(7) Help
[1] [Help]
Display the help files.
[2] [About]
Display the version information of this application.
* The menu items shown in gray cannot be selected.
