Chapter 2 - Interface
X501NET System Configuration Manual © 2008 Ronan Engineering Company 37
2.10.2.14 Timeout T0 Field
The Timeout T0 field is the controls the T0 delay as defined in the IEC 60870-5-104 standard.
The T0 delay is the timeout interval in seconds for connection establishment.
2.10.2.15 Timeout T1 Field
The Timeout T1 field is the controls the T1 delay as defined in the IEC 60870-5-104 standard.
The T1 delay is the timeout interval in seconds for function confirmations.
2.10.2.16 Timeout T2 Field
The Timeout T2 field is the controls the T2 delay as defined in the IEC 60870-5-104 standard.
The T2 delay is the timeout interval in seconds for ACK receptions.
2.10.2.17 Timeout T3 Field
The Timeout T3 field is the controls the T3 delay as defined in the IEC 60870-5-104 standard.
The T3 delay is the maximum inactivity timeout interval in seconds.
2.10.2.18 Status Point Address Field
The Status Point Address field displays the virtual point address of the X501NET’s status
word and allows this point address to be changed by administrators.
2.10.2.19 Transmit Queue Size Field
This parameter specifies the size of the event buffer.
2.10.2.20 Sync on TimeSync Command Field
This parameter specifies whether to accept the time sync command from and IEC60870 server,
since this synchronization is not precise.
2.11 X110 Connection Configuration Page
The X110 Connection Configuration page is used to setup the Ethernet communication
with up to four X110 Annunciators via TCP or an unlimited number of X110 Annunciators
attached to the same LAN of a UDP broadcast connection.
