Chapter 2 - Interface
X501NET System Configuration Manual © 2008 Ronan Engineering Company 12
To login in, the user is required to enter User ID (User1 in the example screen shown above),
Password (asterisks automatically replaces characters typed in the password field to help
maintain system security) and press the
Login button.
2.3.1 Login Page Buttons
Button Action
Pressing the
Login button causes the User ID and
Password entered to be checked and, if valid, the
appropriate access level is granted.
Pressing the
Main Menu button takes the user to the Main
Menu page.
2.3.2 User ID and Password
Both User IDs and Passwords are case sensitive (i.e. A is not the same as a). See Section 4.8
for information on how add users to the system.
2.4 Point Status Page
The Point Status page displays the status of every input point in the X501NET. As a result
the page is very long. To assist in page navigation, there are buttons at the top and bottom of the
page to jump from top to bottom.
This page does not allow for direct modifications of the point configuration parameters.
However, each row displays a link to the corresponding Point Configuration page.
