Chapter 2 - Interface

X501NET System Configuration Manual © 2008 Ronan Engineering Company 17

2.5.2.6 Tag/Message

The Tag/Message field contains either a tag name assigned to the point or the Message if the
event is generated by the X501NET (see section 2.5.2.4).

2.5.2.7 Legend/Description

The Legend/Description field contains either a legend associated with the current point state
or the description associated with the event generated by the X501NET (see section 2.5.2.4).

2.6 General Configuration Page

The General Configuration page shows the device’s physical and logical addresses, and
time subsystem parameters. This page also allows these parameters to be changed if the user has
Administrator access rights.
