Beamage-M 2 User Manual Revision 2.0 31
Table 3-2 2D M 2 Image Buttons
Select active area
Selects a region of interest for the M 2 calculation. All pixels outside this region
will not be considered. This is especially useful if you have unwanted reflections
in your image.
Print Screen Saves the current 2D display in a .bmp file.
Reset View
Resets the display settings to their original parameters. This includes the region
of interest.
Show/Hide
Diameters
Displays the ellipse that corresponds to the beam diameter of each beam along
the path.
