FEC AFC1500 Operations Manual Chapter 4: System Setup and Wiring (Rev. 6:10/09)
Page 4-23
4.7.4 Bank Output Servo Error Table
The Bank Servo Error Table defines the type of servo error (fault) output from Bank 4 Data
bits 4-7(see above)
SV ERR
SV AMP ERR
(Data 4)
2
(Data 7)
1
(Data 6)
0
(Data 5)
DESCRIPTION
ON OFF OFF OFF
ON OFF OFF ON Over current or SAN type mismatch.
ON OFF ON OFF Resolver abnormal.
ON OFF ON ON SAN unit overheated.
ON ON OFF OFF
ON ON OFF ON Internal voltage level abnormal.
ON ON ON OFF Input voltage abnormal.
ON ON ON ON Overload.
OFF - - - No error
