AFC1500 Operations Manual
Appendix A (Rev. 5: 02/08)
Appendix A-3
AFC1500 Data Parameter Setting Blank Form
ITEM
DATA SETTING
PARM
D- No
DATA
System
0
00
TORQUE UNIT #.
0
01
ROM VERSION (Not adjustable)
0
02
AMPLIFIER VERSION (Not adjustable)
0
03
FASTENING FUNCTION VERSION(Standalone/Multi)
0
04
External Gear Ratio
Tool Data
0
10
TOOL # (not adjustable)
0
11
TOOL CAL TORQUE.
Factory Set
0
12
CAL. VOLTAGE
0
13
ZERO TORQUE VOLTAGE
0
14~1A
FEC In House Management Data
0
1B / 1C
TOOL FASTENING COUNT (1
ST
4 DIGITS / LAST 4 DIGITS)
Tool Type
0
20
TOOL MODEL #
Time Setup
(SAN3-DPx ONLY)
0
30
YEAR “YYYY” EX. “2009”
0
31
MONTH & DATE “mmdd” EX. “0923” (SEPT. 23)
0
32
HOUR & MINUTE “hhmm” EX. “1759” 17:59
0
33
SECONDS “ss” EX. “55” 55 SECONDS
Torque
1~16
00
FASTENING MODE (METHOD + STEPS)
1~16
10
CALIBRATION TORQUE
1~16
11
PEAK TORQUE LOW LIMIT
1~16
12
PEAK TORQUE HIGH LIMIT
1~16
13
STANDARD (STD) TORQUE
1~16
14
SPEED CHANGE TORQUE
1~16
15
1ST TORQUE
1~16
16
SNUG TORQUE
1~16
17
THRESHOLD (THR) TORQUE
1~16
18
CROSSOVER (CROS) TORQUE
1~16
19
TORQUE INHIBIT LIMIT
1~16
1A
OFFSET TORQUE LIMIT/1 PULSE REVERSE LIMIT
1~16
1B
BREAKAWAY TORQUE LIMIT
1~16
1C
FINAL TORQUE LOW LIMIT
1~16
1D
FINAL TORQUE HIGH LIMIT
1~16
1E
2ND RATE START TORQUE
Angle
1~16
20
ANGLE LOW LIMIT
1~16
21
ANGLE HIGH LIMIT
1~16
22
STANDARD (STD) ANGLE
1~16
23
1ST ANGLE
1~16
24
CROSSOVER ANGLE
1~16
25
ANGLE CORRECTION
1~16
26
2ND RATE START ANGLE (NOT USED)
1~16
27
3RD RATE START ANGLE (NOT USED)
Rate
1~16
30
1ST RATE LOW LIMIT
1~16
31
1ST RATE HIGH LIMIT
1~16
32
2ND RATE LOW LIMIT
1~16
33
2ND RATE HIGH LIMIT
1~16
34
3RD RATE HIGH LIMIT
1~16
35
3RD RATE HIGH LIMIT
Time
1~16
40
INITIAL TIME
1~16
41
1ST TIME HIGH LIMIT
1~16
42
FINAL TIME HIGH LIMIT
1~16
43
FIRST TIME LOW LIMIT
1~16
44
FINAL TIME LOW LIMIT
1~16
45
RAMP UP TIME
1~16
46
RAMP DOWN TIME
1~16
47
REVERSE RAMP UP TIME
1~16
48
TORQUE RECOVERY TIME
Speed
1~16
50
INITIAL SPEED
1~16
51
FREE RUN SPEED
1~16
52
SLOW DOWN SPEED
1~16
53
TORQUE SPEED
1~16
54
REVERSE 1,2 SPEED
1~16
55
REVERSE 3 / OR 1 PULSE REVERSE SPEED
1~16
56
OFFSET CHECK SPEED
Revolutions
1~16
60
FREE RUN REVOLUTIONS
1~16
61
TORQUE INHIBIT REVOLUTIONS
1~16
62
OFFSET CHECK REVOLUTIONS
1~16
63
REVERSE 2 REVOLUTIONS
1~16
64
REVERSE 3 REVS. / OR 1 PULSE REV. TIME
1~16
68
RUNDOWN REVOLUTIONS LOW LIMIT
1~16
69
RUNDOWN REVOLUTIONS HIGH LIMIT
Current
1~16
70
FULL SCALE CURRENT VALUE
1~16
71
HIGH CURRENT LIMIT
1~16
72
LOW CURRENT LIMIT
1~16
73
FASTENING CURRENT LIMIT
