AFC1500 Operations Manual

Chapter 9: Troubleshooting (Rev. 6: 10/09)

Page 9-13

9.10 Parameter Error

9.10.1 Code 9-0

PARAMETER ERROR / MISSING SPEED PRESET

Some speed preset is not setup in the parameter number selected or the wrong parameter
number has been selected by the PLC.

RECOVERY:
1. Verify that the parameter number that is being selected by the PLC is configured in the
controller.
2. Check that the reverse speed preset is not <0> or out of the specified speed range of the
tool

9.10.2 Code 9-1

PARAMETER ERROR / MISSING TIME or SPEED PRESET

Some Time or Speed preset is not setup in the parameter number selected or the wrong pa-
rameter number has been selected by the PLC.

RECOVERY:
1. Verify that the parameter number that is being selected by the PLC is configured in the
controller.
2. Check that the reverse speed preset is not <0> or out of the specified speed range of the
tool

9.10.3 Code 9-2

PARAMETER ERROR / PARAMETER SELECT ERROR

The parameter selected was empty.

RECOVERY:
1. Verify that the parameter number that is being selected by the PLC is configured in the
controller.
2. Check that the fastening presets are not <0> or out of the specified range for the tool.

9.10.4 Code 9-3

PARAMETER ERROR / MISSING REVERSE SPEED

The Reverse speed preset is missing.
RECOVERY:
1. Verify that the parameter number that is being selected by the PLC is configured in the
controller.
2. Check that the reverse presets are not <0> or out of the specified range for the tool.

9.10.5 Code 9-4

PARAMETER ERROR / TORQUE SPEED NOT SET

The Torque speed preset is missing.

RECOVERY:
1. Verify that the parameter number that is being selected by the PLC is configured in the
controller.
2. Check that the Torque speed is not set as <0> or out of the specified range for the tool.

9.10.5 Code 9-5

PARAMETER ERROR / TORQUE SETUP ERROR

One of the Torque presets is out of range

RECOVERY:
1. Verify that the Torque presets are in range for the tool size.
2. Check that the torque presets are not <0> or setup as specified in 6.1.1.
