Chapter 3: System Description
Page 3-10
3.4.2 SAN(3)-DP2/DP4 Communication Protocol
Communication protocol from the SAN(3)-DP2/DP4 is as follows;
Speed:
9600bps
Parity: NONE
Data Bits: 8 Bit
Stop Bit: 1 Bit
3.4.3 SAN(3)-DP2/DP4 Communication Format
The data output from the SAN(3)-DP2/DP4 is a formatted ASCII output. This can be connected to a
serial printer, computer or other peripheral device. 78 bytes of data is output per fastening. The data
format is described in the table below.
Byte 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Desc. Cycle Count
Spindle
Number
Parameter
Number
PK
TQ
ASCII
Hex
30H 30H 30H 31H 20H 20H 30H 31H 20H 20H 20H 20H 31H 20H 20H 30H
Data 0 0 0 1 0 1 1 0
Byte 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
Desc. Peak Torque (PK TQ) Judge Final Angle Judge Final Torque (FN TQ)
ASCII
Hex
31H 2EH 33H 34H 4CH 20H 20H 20H 35H 30H 20H 20H 20H 31H 2EH 33H
Data 1 . 3 4 L 5 0 1 . 3
Byte 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Desc. FN
TQ
Judge 1st Rate Judge 2nd Rate Judge
ASCII
Hex
34H 4CH 20H 30H 2EH 31H 32H 33H 20H 20H 30H 2EH 31H 32H 33H 20H
Data 4 L 0 . 1 2 3 0 . 1 2 3
Byte 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63
Desc. 3rd Rate Judge 1st Time Judge
ASCII
Hex
20H 30H 2EH 31H 32H 33H 20H 20H 20H 31H 30H 2EH 30H 20H 20H
Data 0 . 1 2 3 1 0 . 0
Byte 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78
Desc. 2nd Time Judge Judge CR LF
ASCII
Hex
20H 20H 32H 2EH 30H 20H 20H 20H 20H 58H 20H 20H 20H 0DH 0AH
Data 2 . 0 X
Total Judgment: “X” = 58h, “O” = 4Fh
