3 bank select table – FEC AFC1500 User Manual

Page 64

Chapter 4: System Setup and Wiring

Page 4-20

4.7.3 Bank Select Table

Bank Select inputs are used to “multiplex” the output signals allowing up to 32 signals from
only 8 physical outputs. By changing the input conditions of these two inputs, up to four
“Banks” may be selected, changing the definition of each output point.

BANK

BANK SELECT

INPUT

PLC / SAN UNIT BANK DATA

BANK DATA SIGNAL NAME

SIGNAL DESCRIPTION

OFF OFF

DATA 0
(SAN2 PIN 25)
(SAN3 PIN 31)

REJECT

Output when the fastening result is a REJECT. Indicates that the

spindle has failed the fastening limits. This output remains active

until the START signal or RESET signal is input.

DATA 1
(SAN2 PIN 24)
(SAN3 PIN 30)

ACCEPT

Output when the fastening result is a ACCEPT. Indicates that the

spindle is within the fastening limits. This output remains active until

the START signal or RESET signal is input.

DATA 2
(SAN2 PIN 23)
(SAN3 PIN 29)

ABNORMAL

Output when an Abnormal condition occurs, indicates that the

System has detected an internal fault, and can no longer proceed.

An Abnormal condition must be corrected before the System will re-

sume normal operation.

DATA 3
(SAN2 PIN 22)
(SAN3 PIN 28)

READY

Output when the system is in READY condition to operate, and in-

puts are enabled. This signal is inactive (off) when the BUSY out-

put is active (on).

DATA 4
(SAN2 PIN 21)
(SAN3 PIN 27)

BUSY

Output after a START signal is received, and active until the fas-

tening cycle is complete and the READY signal is output.

DATA 5
(SAN2 PIN 20)
(SAN3 PIN 26)

TORQUE HIGH

REJECT

Output when Fastening resulted in a Torque High Reject.

DATA 6
(SAN2 PIN 19)
(SAN3 PIN 25)

TORQUE LOW

REJECT

Output when Fastening resulted in a Torque Low Reject.

DATA 7
(SAN2 PIN 18)
(SAN3 PIN 24)

BYPASS

Output when the spindle is bypass either via PLC input or the

San Unit front panel switch.

DATA 8
(SAN3 PIN 34)

NOT USED

DATA 9
(SAN3 PIN 33)

NOT USED

DATA 10
(SAN3 PIN 32)

DATA

AVAILABLE

Output when the fastening result data is ready to report.

Turns off when the fastening data being reported.

DATA 7
(SAN3 PIN 22)

TRQ. RECV.

Output while the system is in torque recovery mode.
