Chapter 2: Specifications
Page 2-4
2.3 SAN Unit Specifications
ORIGINAL SAN UNIT TYPE SAN2 - 12 SAN2 - 24 SAN2 - 40 SAN2 - 80 SAN2 – 120
TOOL MOTOR TYPE RM1 RM2 RM3 RM4 RM5
TOOL MAX. TORQUE
4.0 Kgfm
(39Nm)
4.0 Kgfm
(39Nm)
30.0 Kgfm
(294Nm)
80.0 Kgfm
(784Nm)
500 Kgfm
(4093Nm)
MOTOR MAX. POWER 60W 80W 200W 1500W 3000W
MOTOR RATED CURRENT 1A (RMS) 2A (RMS) 3A (RMS) 11A (RMS) 21A (RMS)
SAN INPUT POWER 180-242VAC 50/60Hz
SAN IDLE POWER
CONSUMPTION (watt/hour)
18wh IDLE
SAN AVERAGE POWER
CONSUMPTION (watt/hour)*
25wh 43wh 95wh 134wh
SAN MAX. MOMENTARY
CURRENT (Inrush)
9.5A 18A 38.6A 79.2A 116.2A
SAN UNIT OUTPUT POWER 270-300VAC PWM
UPDATED SAN UNIT TYPE SAN3 - 24
SAN3 –
24HM
SAN3 - 40
SAN3 –
60HM
SAN3 –
120TM
SAN3 –
120WM
TOOL MOTOR TYPE RM1 RM2 RH1 RM3 RH3 RM4 RM5
TOOL MAX. TORQUE
4.0 Kgfm
(39Nm)
30.0 Kgfm
(294Nm) (200Nm)
80.0 Kgfm
(784Nm)
500 Kgfm
(4093Nm)
MOTOR MAX. POWER 60W 80W 70W 200W 1500W 3000W
MOTOR RATED CURRENT 1A (RMS) 2A (RMS) 2A (RMS) 3A (RMS) 6A (RMS) 11A (RMS) 21A (RMS)
SAN INPUT POWER 180-242VAC 50/60Hz
SAN IDLE POWER
CONSUMPTION (watt/hour)
18wh IDLE
SAN AVERAGE POWER
CONSUMPTION (watt/hour)*
25wh 43wh 112wh 95wh 134wh
SAN MAX. MOMENTARY
CURRENT (Inrush)
9.5A 18A 19A 38.6A 53.7A 79.2A 116.2A
SAN UNIT OUTPUT POWER 270-300VAC PWM
* Watt hours measured using the SAN unit at 60% duty/95% torque capacity
CAUTION: If the equipment is powered on and off repeatedly, internal circuit protec-
tion devices may trip due to high in-rush current overload. It may take up to five mi-
nutes of “off” time to clear the self-protection circuit.
{ { { { Controller Processor: 32-bit RISC (Reduced Instruction Set CPU)
{ Parameter / Firmware Storage: Flash ROM
{ Fastening Method: Torque, Angle and Current Control Method
{ Torque Rate Calculation: 3 ranges
{ { { { Data Communications: (2) - RS485 communication ports: (1) for AFC User
Console Software and (1) for Multi Unit Communications
