Manual Mode
53
The IV Protocol editor
The lower part of the "Measurement" tab is dedicated to IV "Voltage Step Protocol"
recordings.
The display will show the IV current traces after loading and applying an IV protocol. IV protocols
are started by clicking the "Apply" button and stopped before finishing with the "Stop" button.
Use the "Load" button to open the "Load Voltage Step Protocol" dialog in which you can
select an IV protocol. Choose TMC test for example, a predefined IV protocol in order to get
familiar with the IV editor.
The name of the desired protocol is displayed in the "Protocol" window.
