Analysis with Roboocyte2+
109
Exporting Parameters from List View Table
To export any of the parameters listed in the “List View” table, select "Table" and move these
parameters from left to right - for example "Well", "conc 1", "unit 1", "Minimum", "Pos. Min.".
After click on "ok", the ASCII-file "name.Datatable.dat" will be generated.
Well
conc. 1
unit 1
Minimum
Pos. Min.
B12
30
M
-5684
11685
B12
3
M
-164
21920
B12
10
M
-1107
13537
B12
30
M
-4956
16349
Exporting Results: Dose-Response Curve
Similarly, you can export data from the “Results Display”, for example dose-response data or
IV dependencies. Select "Results" and all data shown in the “Result Display” will be exported.
This includes the current amplitudes as shown in the display which will be saved under the file
name name_DoseResponseData.dat, C (mM)_B12-0-Min Imin (nA)_B12-0-Min.
C (mM)_B12-0-Min
I min (nA)_B12-0-Min
0,003
-164,6675
0,01
-1107,723
0,03
-4956,9573
0,1
-9501,1613
0,3
-10928,1345
The fit parameters if a dr-fit has been performed which will be saved under the file name
name_FitParameters.dat.
Dose-Response-
Curve-ID
Type-of-Fit Lower-
Asymp
Upper-
Asymp
Midpoint Slope
B12-0-Min Logistic4P
-11754,9
255,4
0,0369
-1,46
