Micro-PWC OPERATOR’S MANUAL
8 User Interface
2.3.2 Keyboard
The IBM AT compatible 101-key keyboard provides the function keys ( F1 through F12) and A LT -function key
combinations. They are used to perform the functions listed in Table 2-1 Where an
A LT -function key combi-
nation is specified, press and hold
A LT simultaneously with the specified function key.
Table 2-1. Function Key Operation
Key Function
F1 Graphic
ALT-F1 Network status display
F2 Summary
F3 Group
F4 Point display
F5 Quick keys
F6 Trend
F7 Alarm review
ALT-F7 Print log
F8 Event review
ALT-F8 Arrange windows
F9 Display forward
ALT-F9 Alarm ack
F10 Display backward
ALT-F10 Window acknowledge
F11 Not used
ALT-F11 Silence
F12 Help
F1 G RAPHIC Displays the graphic selection box. Enter the number of the graphic (one to
10,000), then click OK (or press
R ETURN ) to display a specific graphic. To view
an index list of all graphics which have been defined, click List located at the
bottom of the graphic selection box.
F2 S UMMARY Displays the summary selection box. Enter the number of the summary (one
to 1,000) to be displayed, then click OK. To view an index list of all summaries
which have been defined, click List located at the bottom of the summary
selection box.
After viewing a point or group display called up via the hierarchy (i.e., the user
first called up a summary, then a group from that summary, then a point from
that group), recall the last summary displayed by pressing
F2. This is the only
instance in which the system will automatically vector to the last summary
display shown.
