Luminex IS Version 2.3 (IVD) User Manual
Page 82
Luminex IS Software Manual for Version 2.3- For In Vitro Diagnostic Use
x
MAP Technology
72
Graph Foreground: this is the color used for the bounding
rectangles of the grid, the grid-lines of the graph, and lines that
are used to bound some of the plotting methods (like the
bounding line around bars of the Bar Plotting Method).
Graph Background: this is the color that is used as the
background color of the graph's grid.
Table Background: This is the color used in filling the table's
rectangle. Currently, this feature is not used.
Table Foreground: This is the color used in bounding the
table's rectangle, and for the text inside the table. Currently,
this feature is not used.
Figure 44 Customization Dialog Box—Color Tab
•
Style Tab—use the Style tab for control of subset color, subset
line type, and subset point type. Subset 1 = line type, and Subset
2 = data point. See Figure 45.
Figure 45 Customization Dialog Box—Style Tab
