Luminex IS Version 2.3 (IVD) - Manual (Page 65)

x MAP Technology Luminex 2.3 Software
PN 89-00002-00-254 Rev. B 55
If you need to recover a deleted batch, select Open Incomplete
Batch from the File menu.
Create a Multi-
Batch
A multi-batch is a set of batches that you want to process
consecutively. You can add batches to the multi-batch from existing
batches in your database, or you can create new batches to add to the
multi-batch. You can include as many batches as you need. The
software does not limit you to a certain number of batches per multi-
batch. Different batches within the multibatch are separated by thick
red lines above the first well and below the last well of each batch.
Multi-batches may span more than one plate. A blue line separates
the graphical representation of the plates. A scroll bar appears along
the bottom of the microtiter plate image so you can view additional
plates.
 To create a multi-batch with new batches:
1. Click New Multi-Batch. The Luminex Multi-Batch Setup dialog
box opens, shown in Figure 30.
Figure 30 Luminex Multi-Batch Setup Dialog Box
2. In the Luminex Multi-Batch dialog box, click New Batch.
3. Create a New Batch. The procedure is shown on page 50. Click
Save and Load instead of Save Only when you are finished
setting up the New Batch.
