Luminex IS Software Manual for Version 2.3- For In Vitro Diagnostic Use x MAP Technology
12
• Green text represents a successful system calibration,
verification command, acquisition, or maintenance functions.
• Red text represents failed commands, errors, or warnings.
• Black text represents normal processes and actions.
• Yellow shading indicates that a detailed description about the
processes or actions is available. This color may vary depending
on your tool tip color system settings.
To view details of a message, double-click the shaded row. A
dialog box opens providing details. To clear the Message log,
right-click in the Message Log area, and click Clear on the menu.
Acquisition Detail
Tab
The Acquisition Detail tab offers advanced batch sample monitoring
and “on the fly” data acquisition without templates. The primary
function is real-time monitoring of batch sampling during acquisition
through a display of sample bead statistics, histogram, and dot plot
data.
During batch acquisition, bead statistics can be useful if batch errors
occur. For example, if samples are constantly failing due to
insufficient bead count, you can monitor whether the failure is due to
low bead concentration or if other assay problems are present.
Acquisition Detail tab features:
• Batch Name and Description
• Batch Data Area
• Acquisition Detail Toolbar
• Histogram
• Dot Plot
Acquisition Detail tab features:
• Batch Name and Description
• Batch Data Area
• Acquisition Detail Toolbar
• Dot Plot
Figure 11 identifies the major features of the Acquisition Detail tab.
Caution: Do not alter kit manufacturer’s predefined templates or
create alternative templates for off-the-shelf IVD kits.
Note: The Message log can be
found at:
C:\Program Files\Luminex\Luminex
100 IS\MessageLog
