Luminex IS Software Manual for Version 2.3- For In Vitro Diagnostic Use x MAP Technology
70
Customization dialog box tabs:
• General Tab—Use this tab to define general parameters. See
Figure 40.
Main and Sub Titles: These edit-boxes allow you to add, edit,
or delete these titles. If no title is present, you can enter one.
Delete all characters from a title to remove it.
Viewing Style: The Graph supports three viewing styles:
Color
Monochrome
Monochrome with Symbols
This allows you to quickly adjust the image to best suit printing
on a monochrome printer. If you include fewer than four
subsets in a graph, then the Monochrome setting will probably
be the best choice. If four or more subsets are included in the
graph, then Monochrome with Symbols will help distinguish
the different subsets.
Font Size: The Graph supports three font sizes, Large,
Medium, and Small. When printing the graph, a font size of
Medium or Small is suggested. On occasion the graph may
automatically reduce the size of the font to produce a higher
quality image.
Show Annotations: Currently, this feature is not used. This
check box allows you to remove or add the annotations from
the image.
Numeric Precision: When exporting text and data from the
Export Dialog, you can define the number of decimal positions
at 0, 1, 2, or 3.
Grid Lines: The Graph can contain vertical grid lines,
horizontal grid lines, both vertical and horizontal grid lines, or
no grid lines. Select the appropriate radio button.
Grid in front of data: Check this option to place the grid in
front of the data graphics. Otherwise, the data graphics are
drawn on top of the grid.
• Axis Tab—Use the Axis tab to change your X axis and Y axis
values and specify whether to display them as linear or log. If
you select Log, use “Auto” or ensure that the “Min” value is
greater than zero. See Figure 42.
