Figure 42 Customization Dialog Box—Axis Tab
•
Font Tab—Use the Font tab to change the appearance of the
fonts that appear in the Main Title, Sub Title, and Subset/ Point/
Axis Label boxes. The bottom of the dialog box displays a
sample of the font as you select it. See Figure 43.
Figure 43 Customization Dialog Box—Font Tab
•
Color Tab—Use the Color tab to define the various color
parameters on the analysis graph. See Figure 44.
Desk Foreground: this is the color that is used when placing
text onto the Desk Background. It includes the main title, sub
title, subset/point labels, grid numbers.
Desk Background: this is the color that surrounds the
bounding rectangle of the graph's grid. That is, the color of the
border that appears behind the text labeling.
Shadow Color: the rectangles that make up the graph's grid
and table are bounded at the bottom/right edges with shadows.
To remove the shadows, choose the same color as the Desk
Background.
