External Views, Xserve G5

Front Panel

Back Panel

Securing Thumbscrews (2)

Drive Module
Status Light

Drive Module Activity Light

Optical Drive

System Identifier Button/Light

Enclosure Lock and Status Light

FireWire 400 Port

On/Standby

Button and Light

Apple Drive
Module Bays (3)

Built-in Ethernet Link Light (Port 2)

Built-in Ethernet Link Light (Port 1)

System Activity Lights

FireWire 800 Ports (2)

Gigabit Ethernet Port(s)

System Identifier Button/Light

Serial Console Port

Power Socket

USB 2.0 Ports (2)

Serial Number Label

Ethernet Activity Lights

Ethernet Link Lights

PCI-X Card Expansion Slots (2)
