Front bezel, Tools, Preliminary steps – Apple Xserve G5 User Manual
Page 41: Part location
Xserve G5 Take Apart - 39
Front Bezel
Front Bezel
Note: Although the illustrations for this procedure are based on Xserve G5, the procedure
is the same for Xserve G5 (Cluster Node).
Tools
The only tool required for this procedure is a Phillips screwdriver.
Preliminary Steps
Before you begin, open the server and place the bottom housing on a sturdy, flat surface.
Part Location
