Optical drive cable, xserve g5, Tools, Preliminary steps – Apple Xserve G5 User Manual
Page 31: Part location
Xserve G5 Take Apart - 29
Optical Drive Cable, Xserve G5
Optical Drive Cable,
Xserve G5
Tools
No tools are required for this procedure.
Preliminary Steps
Before you begin, do the following:
• Open the server and place the bottom housing on a sturdy, flat surface.
• Remove the power supply fan duct.
Part Location
