Page 24: Part location
22 - Xserve G5 Take Apart
PCI Fan Duct
PCI Fan Duct
The PCI fan is attached to a plastic duct; you remove the fan and duct as a unit.
Tools
The only tool required for this procedure is a small flat-blade screwdriver.
Preliminary Steps
Before you begin, open the server and place the bottom housing on a sturdy, flat surface.
Part Location
