Drive interconnect board, Tools, Preliminary steps – Apple Xserve G5 User Manual
Page 62: Part location
60 - Xserve G5 Take Apart
Drive Interconnect Board
Drive Interconnect Board
Tools
No tools are required for this procedure. You may, however, find a Phillips screwdriver
useful in releasing the thumbscrews in step 2 below.
Preliminary Steps
Before you begin, open the server; place the bottom housing on a sturdy, flat surface; and
remove the following:
• hard drives (blank drive carriers can remain in place)
• power supply fan duct
• PCI fan duct
• fan array
Part Location
