Pci riser, Tools, Preliminary steps – Apple Xserve G5 User Manual
Page 19: Part location
Xserve G5 Take Apart -
17
PCI Riser
PCI Riser
Tools
No tools are required for this procedure. You may, however, find a Phillips screwdriver
useful in releasing the thumbscrew in step 1 below.
Preliminary Steps
Before you begin, open the server and place the bottom housing on a sturdy, flat surface.
Part Location
