Logic board, 2 - xserve g5 views internal views, xserve g5 – Apple Xserve G5 User Manual
Page 93
2 - Xserve G5 Views
Internal Views, Xserve G5
Logic Board
FireWire
800
Ports (2)
USB
2.0
Ports (2)
Serial
Port
Ethernet
Ports (2)
System Identifier Button
Battery
DIMM Slots (8)
Optical Drive
Cable
Connector
Power
Supply
Connector
Power Cable
Connector
Fan Array
Connector
Processor
Connector (1)
Processor
Connector (0)
Fan Array Connector
Hard Drive Cable Connectors (3)
Front Panel
Board Cable
Connector
PCI
Fan
Connector
PCI Card Riser
Connector
PMU Reset Button
Firewire Cable Connector
