Power supply, Tools, Preliminary steps – Apple Xserve G5 User Manual
Page 65: Part location
Xserve G5 Take Apart - 63
Power Supply
Power Supply
Tools
No tools are required for this procedure. You may, however, find a Phillips screwdriver
useful in releasing the thumbscrew in step 2 below.
Preliminary Steps
Before you begin, do the following:
• Open the server and place the bottom housing on a sturdy, flat surface.
• Remove the power supply fan duct.
Part Location
