10 -

Xserve G5 Take Apart

DIMMs

Procedure

1. Push down the ejectors on the DIMM slot.

2. Holding the DIMM by both top corners, lift it straight up out of the server.

Warning:

When removing or installing the DIMM, handle it only by the edges. Do not

touch its connectors. Lift the DIMM straight up from the connector to remove it, and insert
it straight down into the connector to install it. Do not rock the DIMM from side to side.

Replacement Note:

The DIMM is designed to fit into the slot only one way. Be sure to

align the notch in the DIMM with the small rib inside the slot.
