Page 55
Xserve G5 Take Apart -
53
Power Cable
Procedure
1. Disconnect the optical drive cable from the logic board and move the cable connector
out of the way.
2. Disconnect the power cable from the drive interconnect board.
3. Disconnect the power cable from the logic board and remove the cable from the
server.
