GF Signet 2760 DryLoc pH_ORP Preamplifier and Connectors - Manual (Page 8)

Georg Fischer Signet LLC, 3401 Aerojet Avenue, El Monte, CA 91731-2882 U.S.A. • Tel. (626) 571-2770 • Fax (626) 573-2057
For Worldwide Sales and Service, visit our website: www.gfsignet.com • Or call (in the U.S.): (800) 854-4090
For the most up-to-date information, please refer to our website at www.gfsignet.com
3-2760.090 Rev. H 05/11 English © Georg Fischer Signet LLC 2011
Accessories and Replacement Parts
Calibration Tools
3-2759
159 000 762 pH/ORP System Tester (adapter cable sold separately)
3-2759.391 159 000 764 2759 Adapter Cable for use w/2760 DryLoc Preamplifi er
3-0700.390 198 864 403 pH Buffer Kit (1 each 4, 7, 10 pH buffer in powder form, makes 50 mL)
5523-0624 159 000 636 Cable, 6 conductor, 24 AWG shielded
3822-7004 159 001 581 pH 4.01 buffer solution, 1 pint (473 ml) bottle
3822-7007 159 001 582 pH 7.00 buffer solution, 1 pint (473 ml) bottle
3822-7010 159 001 583 pH 10.00 buffer solution, 1 pint (473 ml) bottle
3822-7115 159 001 606 20 gram bottle Quinhydrone for ORP calibration
3-2700.395 159 001 605 Calibration kit: included 3 Polypropylene cups, box as cup stand, 1 pint pH 4.01,
1 pint pH 7.00
Special Request NIST Traceable Certifi cate
Electrodes
DryLoc pH Electrodes
3-2724-10
159 001 547 Combo fl at pH Electrode, 3 KΩ RTD, ¾ in. NPT or Signet fi ttings
3-2724-11 159 001 548 Combo fl at pH Electrode, 3 KΩ RTD, ISO 7/1 R¾ or Signet fi ttings
3-2726-10 159 001 555 Combo bulb pH Electrode, 3 KΩ RTD, ¾ in. NPT or Signet fi ttings
3-2726-11 159 001 556 Combo bulb pH Electrode, 3 KΩ RTD, ISO 7/1 R¾ or Signet fi ttings
3-2726-HF-10 159 001 551 Combo bulb pH Electrode, 3 KΩ RTD, HF resistant, ¾ in. NPT or Signet fi ttings
3-2726-HF-11 159 001 552 Combo bulb pH Electrode, 3 KΩ RTD, HF resistant, ISO 7/1 R¾ or Signet fi ttings
3-2726-LC-10 159 001 559 Combo bulb pH Electrode, 3 KΩ RTD, Low conductivity, ¾ in. NPT or Signet fi ttings
3-2726-LC-11 159 001 560 Combo bulb pH Electrode, 3 KΩ RTD, Low conduct., ISO 7/1 R¾ or Signet fi ttings
3-2764-1 159 000 943 Differential pH Electrode, 3 KΩ RTD, 1 in. NPT process connection
3-2764-3 159 000 945 Differential pH Electrode, 300 Ω RTD, 1 in. NPT process connection
3-2766-1 159 000 949 Differential pH Electrode, 3 KΩ RTD, 1 in. NPT process connection
3-2766-3 159 000 951 Differential pH Electrode, 300 Ω RTD, 1 in. NPT process connection
3-2774 159 000 955 Combo fl at pH Electrode, 3 KΩ RTD, ¾ in. NPT process connection
3-2776 159 000 959 Combo fl at pH Electrode, 3 KΩ RTD, ¾ in. NPT process connection
DryLoc ORP (Redox) Electrodes
3-2725-60
159 001 561 Flat ORP Electrode, 10KΩ ID, ¾ in. NPT or Signet installation fi ttings
3-2725-61 159 001 562 Flat ORP Electrode, 10KΩ ID, ¾ in. ISO 7/1 R¾ or Signet installation fi ttings
3-2765-1 159 000 946 Differential ORP (Redox) Electrode, 10 KΩ ID, 1 in. NPT process connection
3-2765-3 159 000 948 Differential ORP (Redox) Electrode, 300 Ω RTD, 1 in. NPT process connection
3-2767-1 159 000 952 Differential ORP (Redox) Electrode, 10 KΩ ID, 1 in. NPT process connection
3-2767-3 159 000 954 Differential ORP (Redox) Electrode, 300 Ω TC, 1 in. NPT process connection
3-2775 159 000 957 Combo fl at ORP (Redox) Electrode, 10 KΩ ID, ¾ in. NPT process connection
3-2775-1 159 000 958 Combo fl at ORP (Redox) Electrode, no Temp, ¾ in. NPT process connection
3-2777 159 000 961 Combo bulb ORP (Redox) Electrode, 10 KΩ ID, ¾ in. NPT process connection
3-2777-1 159 000 962 Combo bulb ORP (Redox) Electrode, no Temp, ¾ in. NPT process connection
Mfr. Part No. Code Description
3-2760-1 159 000 939 Submersible Preamplifi er with ¾ in. NPT threads and 4.6 m (15 ft) cable
3-2760-2 159 000 940 Submersible Preamplifi er with ¾ in. ISO 7/1R threads and 4.6 m (15 ft) cable
3-2760-3 159 000 941 Submersible Connector with 4.6 m (15 ft) cable and ¾ in. NPT threads
3-2760-4 159 000 942 Submersible Connector with 4.6 m (15 ft) cable and ISO 7/1R ¾ in. threads
3-2760-11 159 001 367 In-line Preamplifi er with ¾ in. NPT threads and 4.6 m (15 ft) cable
3-2760-21 159 001 368 In-line Preamplifi er with ¾ in. ISO 7/1R threads and 4.6 m (15 ft) cable
3-2760-31 159 001 369 In-line Connector with 4.6 m (15 ft) cable and ¾ in. NPT threads
3-2760-41 159 001 370 In-line Connector with 4.6 m (15 ft) cable and ISO 7/1R ¾ thread
Ordering Information
