5 Signet 2760 DryLoc pH/ORP Preamplifi er
Standard output,
¾ in. process connector.
3-2774
3-2775
3-2776
3-2777
Differential output,
1 in. process connector.
3-2764-1
3-2765-1
3-2766-1
3-2767-1
Standard output,
Signet installation fittings
3-2724-10, -11
3-2725-60, -61
3-2726-10, -11
3-2726-HF-10, -11
3-2726-LC-10, -11
3-2756-WT-1
3-2756-WTP-1
3-2757-WT
3-2757-WTP
3-2760-1
3-2760-2
3-2760-1
3-2760-2
3-2760-11
3-2760-21
3-5700 pH/ORP Monitor
V +
Red Wire
V -
Black wire
-
+
T -
White wire
T +
Green wire
Iso. Gnd
Blue wire
Blue Iso. Gnd
mV Input
Brown wire
Brown mV
4-20
mA
Red V+
Black V-
White T-
Green T+
Connect this terminal to Earth GND to reduce electrical interference.
White (Temp)
Green (Temp)
Blue (Iso. Gnd)
Brown (mV input)
Shield
Black (V-)
Red (V+)
12
11
10
9
8
7
6
5
18
17
16
15
14
13
12
11
16
15
14
13
12
11
10
9
3-8750-1 3-8750-2 3-8750-3
ProcessPro pH/ORP Transmitter
3-2760-11
3-2760-21
Any of these electrodes can be connected to the Signet ProPoint and ProcessPro pH instruments using the 3-2760-1(X) or -2(X)
Preamplifi ers.
Wiring diagrams illustrate the actual terminals on these products for convenience.
Wiring to Signet Instruments
R LA 1
2
Signet 8750-X
ProcessPro pH/ORP Transmitter
Signet 5700
ProPoint pH/ORP Monitor
