12. Ordering Information
3-2551-T2-11 159 001 448
3-2551-T2-12 159 001 449
3-2551-V0-11 159 001 257
3-2551-V0-12 159 001 259
3-2551-V1-11 159 001 258
3-2551-V1-12 159 001 260
3-2551-V2-11 159 001 450
3-2551-V2-12 159 001 451
3-2551-P0-11 159 001 105
3-2551-P0-12 159 001 110
3-2551-P1-11 159 001 106
3-2551-P1-12 159 001 111
3-2551-P2-11 159 001 107
3-2551-P2-12 159 001 112
3-2551-T0-11 159 001 108
3-2551-T0-12 159 001 113
3-2551-T1-11 159 001 109
3-2551-T1-12 159 001 114
Sensor Part No.
3-2551
Sensor Body (Transducer) and electrodes/grounding ring materials - Choose one
-P
Polypropylene and 316L SS
-T PVDF and Titanium
-V PVDF and Hastelloy C
Pipe size - Choose one
0
DN15 to DN100 (½ to 4 in.)
1 DN125 to DN200 (5 to 8 in.)
2 DN250 to DN900 (10 to 36 in.)
Display Options - Choose One
-1 No Display
Output options - Choose One
1
Frequency, Digital (S 3 L)
2 4 to 20 mA output
3-2551 -P 0 -1 2 Example Part Number
Replacement Parts and Accessories
Mfr. Part No. Code Description
1220-0021 198 801 186 O-ring, FPM
1224-0021 198 820 006 O-ring, EPDM
1228-0021 198 820 007 O-ring, FFPM
3-2551-11 159 001 215 Magmeter electronics, no display, frequency or Digital (S 3 L) output
3-2551-12 159 001 216 Magmeter electronics, no display, 4 to 20 mA output
3-2551-P0 159 001 211 PP/316L SS, DN15 to DN100 (½ to 4 in.) pipe
3-2551-P1 159 001 212 PP/316L SS, DN125 to DN200 (5 to 8 in.) pipe
3-2551-P2 159 001 444 PP/316L SS, DN250 to DN900 (10 to 36 in.) pipe
3-2551-T0 159 001 213 PVDF/Titanium, DN15 to DN100 (½ to 4 in.) pipe
3-2551-T1 159 001 214 PVDF/Titanium, DN125 to DN200 (5 to 8 in.) pipe
3-2551-T2 159 000 445 PVDF/Titanium, DN250 to DN900 (10 to 36 in.) pipe
3-2551-V0 159 001 376 PVDF/Hastelloy-C, DN15 to DN100 (½ to 4 in.) pipe
3-2551-V1 159 001 377 PVDF/Hastelloy-C, DN125 to DN200 (5 to 8 in.) pipe
3-2551-V2 159 000 446 PVDF/Hastelloy-C, DN250 to DN900 (10 to 36 in.) pipe
7300-7524 159 000 687 24 VDC Power Supply 7.5 W, 300 mA
7300-1524 159 000 688 24 VDC Power Supply 15 W, 600 mA
7300-3024 159 000 689 24 VDC Power Supply 30 W, 1.3 A
7300-5024 159 000 690 24 VDC Power Supply 50 W, 2.1 A
7300-1024 159 000 691 24 VDC Power Supply 100 W, 4.2 A
3-0250 159 001 538 USB to Digital (S 3 L) Con¿ guration/Diagnostic Tool
3-8050.390-1 159 001 702 Retaining Nut Replacement Kit, NPT, Valox ®
3-8050.390-3 159 310 116 Retaining Nut Replacement Kit, NPT, PP
3-8050.390-4 159 310 117 Retaining Nut Replacement Kit, NPT, PVDF
3-8050.391 159 001 703 Retaining Nut Replacement Kit, NPT, Stainless Steel
3-9000.392-1 159 000 839 Liquid-tight connector kit, 1 set, ½ in. NPT
Part Number Code Part Number Code
