Series 6A Operation & Maintenance – Technical Data
6A O & M : 34
Communication
Communications group and class
According to technical specification of the Fieldbus Foundation for H1 communication
Function blocks Group 3, Class 31PS (publisher, subscriber)
1 resource block (RB2)
1 analog output function block (AO)
1 PID function block (PID)
1 transducer block (standard advanced positioner valve)
Execution times of the blocks AO: 60 ms
PID: 80 ms
Physical layer profile 123, 511
FF registration Tested with ITK 5.0
Device address 22 (when delivered)
Connections
• Electrical
Screw terminals 2.5
AWG28-12
Cable gland M20x1.5 or
½-14 NPT
Screw terminals 2.5
AWG28-12
Ex d certified cable gland
M20x1.5, ½-14 NPT or
M25x1.5
Screw terminals 2.5 AWG28-12
Cable gland M20x1.5 or ½-14 NPT
• Pneumatic Female thread G¼ EN ISO 228-1 (¼ -18 NPT)
External position sensor
(potentiometer or NCS; as option)
with the following peak values
• U
o
– 5 V
• I
o
(static) – 75 mA
• I
s
(short-time) – 160 mA –
• P
o
– 120 mW
• Maximum permissible external
capacitance C
o
– 1 μF
• Maximum permissible external
inductance L
o
– 1 mH
SIPART PS2 FF Basic device
without Ex protection
Basic device
with Ex d protection
(flameproof enclosure)
Basic device
with Ex ia/ib protection
Basic device
with Ex n/
dust protection
Technical specifications
