Series 6A Operation & Maintenance – Calibration & Commissioning
6A O & M : 17
41) YCUP Upper value for tight
closing
0.0 … 99.5 … 100% Used to set the value for tight “Tight closing below”
and “Tight closing above”. Factory setting is “99.5”
Normally
Open
Normally
Closed
Functions while in binary input mode.
OFF Factory setting.
on -on Binary message from peripherals
bloc1 Used to lock the configuration operation
bloc2
uP -uP
doWn -doWn
Actuator regulating to the valve specified by
parameters “YA” and “YE”
StoP -StoP Piezo valves are blocked. Actuator remains at last
position.
42) BIN1 2) Function of BE1
PST -PST Used to trigger a partial stroke test
Normally
Open
Normally
Closed
Functions while in binary input mode.
OFF Factory setting.
on -on Binary message from peripherals
uP -uP
doWn -doWn
Actuator regulating to the valve specified by
parameters “YA” and “YE”
StoP -StoP Piezo valves are blocked. Actuator remains at last
position.
43) BIN2 2) Function of BE2
PST -PST Used to trigger a partial stroke test
Normal Inverted
Off
44) AFCT 3) Alarm Function Used to determine the value at which going above or
below a given offset or angle will result in a
message.
45) A1 Trigger threshold, alarm 1 0.0 … 10.0 … 100 %
46) A2 Trigger threshold, alarm 2 0.0 … 90.0 …100%
Used to specify when an alarm should be displayed.
Normal Inverted 47) FCT 3) Function for fault
message output
Cannot be switched off. Can be suppressed by
switching to “No Automatic Mode”
48) TIM Monitoring time for
setting of fault message
Auto / 0 … 100 Used to set the time in seconds that the positioner
must have reached the regulated condition.
49) LIM Response threshold for
fault message
Auto / 0 … 100 Used to set a value for the permissible size of the
regulation device to trigger a fault message.
no
Strt
50) PRST Preset (factory setting)
oCAY
Used to restore factory settings and reset
initialization. Press increment button for 5 seconds.
OFF
On1
On2
51) XDIAG Activation of extended
diagnostics
On3
Used to activate extended diagnostics.
FSVL Actuator controlled using the parameterization safety
point. Effective after a power failure.
FSSP Actuator controlled using the last effective set point
52) FSTY Safety Seating
FSAC Valves move to location based on spring force.
(Factory Defined)
