8 R&S ® CMU200 Universal Radio Communication Tester Version 09.00, October 2008
Phase noise single sideband, f < 2.2 GHz
20 kHz to 250 kHz <–100 dBc, 1 Hz
250 kHz to 400 kHz <–110 dBc, 1 Hz
Carrier offset
≥400 kHz <–118 dBc, 1 Hz
f < 2.2 GHz
30 Hz to 15 kHz <50 Hz, rms
<200 Hz, peak
Residual FM
ITU-T (formerly CCITT) <5 Hz, rms
f < 2.2 GHz Residual AM
ITU-T (formerly CCITT) <0.02 %, rms
Power meter (wideband)
Frequency range 100 kHz to 2700 MHz
Level range
continuous power 3
10 MHz to 2200 MHz +6 dBm to +47 dBm (50 W)
2200 MHz to 2700 MHz +10 dBm to +47 dBm (50 W)
RF 1
peak envelope power 4 (PEP) +53 dBm (200 W)
continuous power
10 MHz to 2200 MHz –8 dBm to +33 dBm (2 W)
2200 MHz to 2700 MHz –4 dBm to +33 dBm (2 W)
RF 2
peak envelope power 4 (PEP) +39 dBm (8 W)
continuous power and PEP
10 MHz to 2200 MHz –33 dBm to 0 dBm
RF 4 IN
2200 MHz to 2700 MHz –29 dBm to 0 dBm
Level uncertainty
input level +10 dBm to +20 dBm
50 MHz to 2700 MHz <1.0 dB 5
input level +20 dBm to +47 dBm
RF 1
50 MHz to 2700 MHz <0.5 dB 5, 6
input level –4 dBm to +6 dBm
50 MHz to 2700 MHz <1.0 dB 5
input level +6 dBm to +33 dBm
RF 2
50 MHz to 2700 MHz <0.5 dB 5
input level –29 dBm to –19 dBm
50 MHz to 2700 MHz <1.5 dB
input level –19 dBm to 0 dBm
RF 4 IN
50 MHz to 2700 MHz <0.8 dB
in manual mode 0.1 dB Level resolution
in remote control mode 0.01 dB
3 50 W in temperature range +5 °C to +30 °C, linear degradation down to 25 W at +45 °C.
4 Mean value of power versus time must be equal to or less than permissible continuous power.
5 Temperature range +5 °C to +20 °C or +35 °C to +45 °C and f > 2200 MHz: add 0.2 dB.
6 Calibrated for input level > +33 dBm only in frequency range 800 MHz to 2000 MHz.
