Version 09.00, October 2008 R&S ® CMU200 Universal Radio Communication Tester 27
Output level uncertainty in temperature range +20 °C to +35 °C
output level ≥ –108 dBm
f < 2200 MHz <0.5 dB
RF 1, RF 2
f ≥ 2200 MHz <0.7 dB
–80 dBm to +4 dBm
f < 2200 MHz <0.7 dB
RF 3 OUT
f ≥ 2200 MHz <0.9 dB
Output level uncertainty in temperature range +5 °C to +45 °C
output level ≥ –108 dBm
f < 2200 MHz <0.7 dB
RF 1, RF 2
f ≥ 2200 MHz <1.5 dB
–80 dBm to +4 dBm
f < 2200 MHz <0.9 dB
RF 3 OUT
f ≥ 2200 MHz <1.5 dB
Modulation
Dual BPSK 1.2288 Mcps
AWGN see AWGN generator
Carrier suppression >35 dB
Waveform quality ( ρ) factor >0.985
Code channel level uncertainty relative to total 1xEV-DO output power approx. 0.1 dB
Code channel resolution 0.1 dB
relative to total 1xEV-DO output power
PICH, SYNC, FCH, SCH0, SCH1, PCH –20 dB to –1 dB
Code channel level range
QPCH (relative to PICH level) –5 dB to +2 dB
AWGN generator
Bandwidth >1.8 MHz
Output level resolution 0.1 dB
Output level uncertainty bandwidth 1.23 MHz approx. 0.2 dB
Output level range relative to total 1xEV-DO output power –20 dB to +4 dB
Supported applications in signaling mode
Test applications FTAP/RTAP, FETAP/RETAP
Default signaling application
Default packet application
