6 R&S ® CMU200 Universal Radio Communication Tester Version 09.00, October 2008
RF generator
Frequency range 100 kHz to 2700 MHz
Frequency resolution 0.1 Hz
Frequency uncertainty same as timebase + frequency resolution
Frequency settling time <400 µs to Δf < 1 kHz
Output level range
100 kHz to 2200 MHz –130 dBm to –27 dBm RF 1
2200 MHz to 2700 MHz –130 dBm to –33 dBm
100 kHz to 2200 MHz –130 dBm to –10 dBm RF 2
2200 MHz to 2700 MHz –130 dBm to –16 dBm
100 kHz to 2200 MHz –90 dBm to +13 dBm RF 3 OUT
2200 MHz to 2700 MHz –90 dBm to +5 dBm
Output level uncertainty in temperature range +20 °C to +35 °C
output level ≥ –106 dBm
10 MHz to 450 MHz <0.6 dB
450 MHz to 2200 MHz <0.6 dB
2200 MHz to 2700 MHz <0.8 dB
output level > –117 dBm
450 MHz to 2200 MHz <0.6 dB 1
2200 MHz to 2700 MHz <0.8 dB 1
output level –117 dBm to –130 dBm
450 MHz to 2200 MHz <1.5 dB 1, 2
RF 1, RF 2
2200 MHz to 2700 MHz <1.5 dB 1, 2
10 MHz to 450 MHz
output level –80 dBm to +10 dBm <0.8 dB
450 MHz to 2200 MHz
output level –90 dBm to +10 dBm <0.8 dB
2200 MHz to 2700 MHz
RF 3 OUT
output level –90 dBm to +5 dBm <1.0 dB
Output level uncertainty in temperature range +5 °C to +45 °C
output level ≥ –106 dBm
10 MHz to 450 MHz <1.0 dB
450 MHz to 2200 MHz <1.0 dB
2200 MHz to 2700 MHz <1.5 dB
output level > –117 dBm
450 MHz to 2200 MHz <1.0 dB 1
2200 MHz to 2700 MHz <1.5 dB 1
output level –117 dBm to –130 dBm
450 MHz to 2200 MHz <1.5 dB 1, 2
RF 1, RF 2
2200 MHz to 2700 MHz <1.5 dB 1, 2
10 MHz to 450 MHz
output level –80 dBm to +10 dBm <1.0 dB
450 MHz to 2200 MHz
output level –90 dBm to +10 dBm <1.0 dB
2200 MHz to 2700 MHz
RF 3 OUT
output level –90 dBm to +5 dBm <1.5 dB
Output level settling time <4 µs
Output level resolution 0.1 dB
1 Not valid at frequencies of net-clock harmonics.
2 Valid for RF 1 only.
