30 R&S ® CMU200 Universal Radio Communication Tester Version 09.00, October 2008
WCDMA specifications – mobile station (UE) test
Standard 3GPP FDD
Symbol rate 3.84 MHz
Synchronization output 2 BNC connector REF OUT 2
Frequency 30.72 MHz/n, n = 1 to 32
RF generator
non-signaling mode
P-CPICH, P-SCH, S-SCH, P-CCPCH,
PICH, DPCH, up to 4 HS-SCCHs,
HS-PDSCH, E-AGCH, E-RGCH/E-HICH
OCNS R99 16-channel orthogonal channel noise
OCNS R5 6-channel orthogonal channel noise
AWGN bandwidth ≥ 5.76 MHz
Channels
reference measurement channels (RMC)
in line with 3GPP TS 34.121 12.2 kbit/s, 64 kbit/s, 144 kbit/s, 384 kbit/s
signaling mode; codes selectable until
conflict in code space occurs
P-CPICH, P-SCH, S-SCH, P-CCPCH,
S-CCPCH, AICH, PICH,
up to 4 HS-SCCHs, HS-PDSCH, E-AGCH,
E-RGCH/E-HICH
OCNS R99 16-channel orthogonal channel noise
OCNS R5 6-channel orthogonal channel noise
AWGN bandwidth ≥ 5.76 MHz
DPCH signaling radio bearer (SRB) 1.7 kbit/s, 2.5 kbit/s, 3.4 kbit/s, 13.6 kbit/s
DPCH reference measurement channels
(RMC) in line with 3GPP TS 34.121
DL and UL 12.2 kbit/s, 64 kbit/s, 144 kbit/s, 384 kbit/s
DL/UL 144 kbit/s/64 kbit/s, 384 kbit/s/64 kbit/s,
384 kbit/s/144 kbit/s
BTFD 1.95 kbit/s, 4.75 kbit/s, 5.15 kbit/s,
5.9 kbit/s, 6.7 kbit/s, 7.4 kbit/s, 7.95 kbit/s
10.2 kbit/s, 12.2 kbit/s
DPCH voice (echo or speech codec)
NB-AMR 4.75 kbit/s, 5.15 kbit/s, 5.9 kbit/s,
6.7 kbit/s, 7.4 kbit/s, 7.95 kbit/s 10.2 kbit/s,
12.2 kbit/s
Channels
DPCH voice (echo or speech codec)
WB-AMR 6.6 kbit/s, 8.85 kbit/s, 12.65 kbit/s,
14.25 kbit/s, 15.85 kbit/s, 18.25 kbit/s,
19.85 kbit/s, 23.05 kbit/s, 23.85 kbit/s
