20 R&S

®

CMU200 Universal Radio Communication Tester

Version 09.00, October 2008

AMPS specifications – mobile station test

RF generator

Frequency range

signaling mode

US Cellular

869 MHz to 894 MHz

Frequency range

non-signaling mode

10 MHz to 2200 MHz

Frequency resolution

non-signaling mode

1 Hz

Frequency uncertainty

same as timebase,
see base unit specifications

Output level range

RF 1

–130 dBm to –27 dBm

RF 2

–130 dBm to –10 dBm

RF 3 OUT

–99 dBm to +13 dBm

Output level resolution

0.1

dB

Output level uncertainty

see base unit specifications and
add 0.1 dB

FM modulation

Deviation range

100 Hz to 20 kHz

Deviation resolution

1 Hz

Modulation frequency range

100 Hz to 15.999 kHz

Modulation distortion

SINAD, modulation frequency 1 kHz,
deviation 8 kHz, bandwidth 30 Hz to
15 kHz

≥40 dB

Residual FM

bandwidth 300 Hz to 3 kHz

<10 Hz, rms

Deviation uncertainty

modulation frequency 1 kHz,
deviation 8 kHz, bandwidth 30 Hz to
15 kHz

<2 % of setting + residual FM

Deviation frequency response

modulation frequency
300 Hz to 15.999 kHz


≤1 dB

RF analyzer

Frequency range

signaling mode

US Cellular

824 MHz to 849 MHz

Frequency range

non-signaling mode

10 MHz to 2200 MHz

Frequency resolution

non-signaling mode

1 Hz

Frequency uncertainty

same as timebase,
see base unit specifications

Power meter (frequency-selective)

Max. level range

RF 1

0 dBm to +53 dBm

RF 2

–14 dBm to +39 dBm

RF 4 IN

–37 dBm to +0 dBm

Level uncertainty

see base unit specifications

Level resolution

0.1

dB
