Version 09.00, October 2008 R&S ® CMU200 Universal Radio Communication Tester 45
R&S
®
CMU-B41 audio generator/analyzer option
AF generator
Output impedance <4 Ω
Max. output current 20 mA, peak
AF sine generator
Frequency range 20 Hz to 20 kHz
Frequency uncertainty same as timebase + half resolution,
see base unit specifications
Frequency resolution 0.1 Hz
Output level range 10 µV to 5 V
level < 10 mV 10 µV Output level resolution
level ≥ 10 mV 0.1 %
Output level uncertainty level ≥ 1 mV and frequency ≤ 10 kHz ≤1.5 % + resolution
THD+N 10 level ≥ 100 mV into load ≥ 600 Ω ≤0.05 %
THD 10 level ≥ 100 mV into load ≥ 600 Ω ≤0.025 %
AF analyzer
Input impedance 1 M Ω  100 pF
AF voltmeter
Frequency range 50 Hz to 20 kHz
Level range 50 µV to 30 V
level < 1 mV 1 µV Level resolution
level ≥ 1 mV 0.1 %
1 mV ≤ level ≤ 2 V <1 % + resolution Level uncertainty
2 V < level ≤ 20 V <2 % + resolution
THD+N meter
Measurement bandwidth 21 kHz
Frequency range 100 Hz to 10 kHz
Level range 10 mV to 30 V
Resolution 0.01 % THD+N
Inherent distortion 100 mV ≤ level ≤ 20 V <0.05 % THD+N
100 mV ≤ level ≤ 2 V <1 % + inherent resolution Uncertainty
2 V < level ≤ 20 V <2 % + inherent resolution
R&S
®
CMU-U99/B99 RF1 level range identical to RF2 option
With the R&S ® CMU-U99/B99 option installed, the input/output level range and the input/output level uncertainty for RF 1 are the same
as for RF 2.
With the R&S ® CMU-U99/B99 option installed, the VSWR of the RF generator and analyzer at RF 1 is as follows:
VSWR RF generator and RF analyzer
10 MHz to 2000 MHz <1.2
2000 MHz to 2200 MHz <1.4
RF1
2200 MHz to 2700 MHz <1.6
10 Measurement bandwidth 21.9 kHz.
