Version 09.00, October 2008 R&S ® CMU200 Universal Radio Communication Tester 39
Bluetooth
®
specifications
Standards Bluetooth ® Core Specifications
Version 1.1
RF generator
RF channel definition 2402 MHz + k × 1 MHz, k = 0 to 93
Frequency range 2402 MHz to 2495 MHz
Frequency resolution channel spacing in line with standard 1 MHz
Frequency offset range ±500 kHz
Frequency offset resolution 1 kHz
Frequency uncertainty ±1 Hz + drift of timebase,
see base unit specifications
Europe (except France), USA
France
RX/TX single frequency Hopping scheme modes in line with standard
reduced hopping
Output level range modulated signal
RF 1 –106 dBm to –33 dBm
RF 2 –106 dBm to –12 dBm
RF 3 OUT –90 dBm to +5 dBm
Output level uncertainty in temperature range +20 °C to +35 °C
RF 1, RF 2 <0.9 dB
RF 3 OUT <1.1 dB
Output level uncertainty in temperature range +5 °C to +45 °C
RF 1, RF 2 <1.6 dB
RF 3 OUT <1.6 dB
Output level resolution 0.1 dB
Modulation
GFSK AC coupling cut-off frequency 100 Hz 1 Mbps, B × T = 0.5
Modulation index 11110000 pattern,
frequency deviation 160 kHz
0.32
Modulation index range frequency deviation 100 kHz to 220 kHz 0.20 to 0.44
Modulation index resolution 0.01
Modulation index uncertainty 11110000 pattern,
frequency deviation 160 kHz ±5 %
RF analyzer
RF channel definition 2402 MHz + k × 1 MHz, k = 0 to 93
Frequency range 2402 MHz to 2495 MHz
Frequency resolution channel spacing in line with standard 1 MHz
Frequency uncertainty ±1 Hz + drift of timebase,
see base unit specifications
Europe (except France), USA
France
RX/TX single frequency Hopping scheme modes in line with standard
reduced hopping
