State/Timing Modules Specifications and
Characteristics
Key Specifications* and Characteristics
Agilent Model Number 16715A, 16716A, 16717A 16740A, 16741A, 16742A 16750B, 16751B, 16752B 16760A
Maximum state acquisition rate on 16715A, 16716A: 167 Mb/s 200 Mb/s 400 Mb/s [1] Full channel: 800 Mb/s
each channel 16717A, 333 Mb/s [1] Half channel: 1.5 Gb/s
Maximum timing sample rate Timing Zoom: 2 GHz (16716A, Timing Zoom: 2 GHz Timing Zoom: 2 GHz Conventional: 800 MHz
(half/full channel) 16717A only) Conventional: 800/400 MHz Conventional: 800/400 MHz Transitional: 400 MHz
Conventional: 667/333 MHz Transitional: 400 MHz Transitional: 400 MHz
Transitional: 333 MHz
Channels/module 68 68 68 34
Maximum channels on a 340 (5 modules) 340 (5 modules) 340 (5 modules) 170 (5 modules)
single time base and trigger
Memory depth 16715A, 16717A: 4/2M [2] 16740A: 2/1 M [2] 16750B: 8/4M [2] 128/64M [5]
(half/full channel) 16716A: 1M/512K [2] 16741A: 8/4 M [2] 16751B: 32/16M [2]
16742A 32/16 M [2] 16752B: 64/32M [2]
Trigger resources Patterns: 16 Pattern: 16 Patterns: 16 At 800 Mb/s: 4 patterns or
Ranges: 15 Ranges: 15 Ranges: 15 2 ranges, 4 flags, arm in
Edge & Glitch: 2 Edge & Glitch: 2 Edge & Glitch: 2 At 200 Mb/s: same as
Timers: (2 per module) -1 Timers: (2 per module) -1 Timers: (2 per module) -1 16750B/51B/52B
Occurrence Counter: [4] Occurrence Counter: 2 Occurrence Counter: [4] Other speeds: refer to
Global Counters: 2 Global Counter: 2 Global Counters: 2 synchronous state analysis
Flags: 4 Flags: 4 Flags: 4 (page 97) and asynchronous
timing analysis (page 100)
Maximum trigger sequence levels 16 16 16 1.5 Gb/s: 2
800 Mb/s: 4
200 or 400 Mb/s: 16
Maximum trigger sequence speed 16715A, 16716A: 167 MHz 200 MHz 400 MHz 1.5 GHz
16717A: 333 MHz
Trigger sequence level branching 4-way arbitrary “IF/THEN/ELSE” 4-way arbitrary 4-way arbitrary “IF/THEN/ELSE” 800 or 1.5 Gb/s: none
branching “IF/THEN/ELSE” branching 200 Mb/s: arbitrary
branching “IF/THEN/ELSE” branching
400 Mb/s: dedicated next-
state branch or reset
Number of state clocks/qualifiers 4 4 4 1 (state clock only)
Setup/hold time* 2.5 ns window adjustable from 2.5 ns windows adjustable from 2.5 ns window adjustable from 1 ns window adjustable from
4.5/-2.0 ns to -2.0/4.5 ns in 100 ps 4.5/2.0 ns to -2.0/4.5 ns in 100 ps 4.5/-2.0 ns to -2.0/4.5 ns in 100 ps 2.5/-1.5 ns to -1.5/2.5 ns
increments per channel [3] increments per channel [3] increments per channel [3] 10 ps increments per channel
Threshold range TTL, ECL, user-definable ±6.0 V TTL, ECL, user-definable ±6.0 V TTL, ECL, user-definable ±6.0 V -3.0 V to 5.0 V adjustable in
adjustable in 10-mV increments adjustable in 10-mV increments adjustable in 10-mV increments 10-mV increments
* All specifications noted by an asterisk are the performance standards against which the product is tested.
[1] State speeds greater than 167 MHz (16717A) or 200 MHz (16750B, 16751B, 16752B, 16760A) require a trade-off in features.
Refer to “Supplemental Specifications and Characteristics” on page 93 for more information.
[2] Memory depth doubles in half-channel timing mode only.
[3] Minimum setup/hold time specified for a single clock, single edge acquisition. Multi-clock, multi-edge setup/hold window add 0.5 ns.
[4] There is one occurrence counter per trigger sequence level.
[5] Memory depth doubles in half-channel 1.25 Gb/s and 1.5 Gb/s modes only.
