19
LS-500 Reports
Line test reports are available on demand from the console or using the web page. The reports can also be generated by
using the rules engine.
Several report options are available to print or save generated reports. For more information on reports in general, please
refer to either the T5 Series Programming Manual (p / n 000-2142) or the T5 Series Operator’s Guide (p / n 000-2151) or
the TS-550evo FMS Programming Guide (p/n 000-2173).
LS-500 Line Leak Reports
LS-500 Line Leak Reports include any line tests completed within the date range chosen by the user. An example of an
LS-500 report can be found below.
Alarms
When a T5 FMS console is in alarm, the Alarm LED on the front of the console will flash. If the line has been programmed
to shut down the pump on failed test (in the FMS Setup), the pump will be unavailable for all system tests and dispensing
until the line with the active alarm is manually reset. If the condition still exists after reset, the alarm will return. A service
visit may be required to identify and correct the condition.
Warning
Always REMOVE POWER from the console prior to installing/removing a module or performing any
maintenance while the console door is open.
Note: Refer to the Important Safety Messages outlined in the beginning of this manual before performing any console
maintenance.
Note: If this guide is not able to help you correct a Warning or Alarm, please contact FFS Technical Services
(1-800-984-6266).
