Tank Sentinel Operator’s Guide
TABLE 5 - 1 (C
ONTINUED
... )
ALARMS & ERROR MESSAGES
NOTE: Diagnostic text in the left column, is shown bolded { become alarms if active for 48 hours }
#
Printed / Faxed / Displayed
Alarm / Warning Text:
Alarm Type:
System WARNING / Error Descriptions and
ALARM Descriptions
(actions to take)
32
SUMP FULL
SENSOR
TSP-DDS, -DTS BriteSensor @ Channel #N
liquid... Sump Full alarm
(see site policy about
pumping containment sump waste water)
33
VAPOR DETECTED / VAPOR
SENSOR
TSP-DVS BriteSensor @ Channel #N detected
product Vapor in the vapor monitoring well
(Call
service provider [to analyze the leak], call your
local Regulatory agency, and see procedures at
your site.)
34
WATER DETECTED
SENSOR
TSP-DIS*, -DDS, DTS, DVS* BriteSensor @
Channel #N detected Water, some sensors* may
not be able to detect product when water is
present
(see procedures at your site)
35
ALPHA ERROR / ALPHA ERR
/ ALPHA V
SYSTEM
Error in API temperature compensation calculating
ALPHA (check any Special Products -- reprogram
temperature compensation type & API ALPHA
value).
36
API ERROR / API VOL
SYSTEM
Error in API temperature compensation routine
(check any Special Products -- reprogram
temperature compensation type).
37
CPM FAILURE
SYSTEM
No Power / Power is below 5 VDC - Check Power
Supply / Increase Voltage (if possible)
38
CPU CRASH
SYSTEM
WARNING - Central Processing Unit / hardware
failure / power quality problem
39
DATA ERROR / DIM
SYSTEM
Transient communication error between the Tank
Sentinel and TS-DIM unit. This alarm/error will
clear itself automatically.
40
DATA NOT AVAILABLE / DIM
SYSTEM
Transient alarm/error caused when TS-DIM unit is
'busy' performing another task and cannot make
the requested data available until it is not 'busy'.
This alarm/error will clear itself automatically.
41
DIM COMM FAILURE
SYSTEM
Tank Sentinel has lost communications with the
TS-DIM unit. Verify power to the DIM / Verify
proper connection between DIM and console.
42
F14 OPEN / F14 FUS
SYSTEM
WARNING - FUSE F14 is blown... no 5 VDC
Sensor Supply Power. Leak detection sensors are
not working and cannot work without power
(call
service provider immediately to replace F14)
43
FAX HARDWARE FAILURE /
FAX HW FAIL / FAX FAL
SYSTEM
WARNING - Fax Hardware Failure... alarms &
compliance faxes cannot be sent
(call service
provider ASAP)
