Acknowledging Alarms
Page
2 - 7
2
Figure 2.1
External BriteBoxes to Console
Figure 2.2
Typical Station Partial Side-view with One Tank
Of the 4 BriteBoxes that can connect to a Tank
Sentinel system:
1 or 2 can be TS-SEM Sensor Expansion Modules
1 can be a TS-ROM Relay Output Module, and
1 can be either a TS-TGI Tank Gauge Interface
module, or
a TS-CIM Control I/O Module
INPUT S
FROM SIGNAL DEVICES
OUT PUT S
T O LOAD DEVICES
T O LEAK
DET ECT ION
SENSORS
TANK GUAGE I NT ERFA CE
M ODUL E
TS-T GI
REL AY OUTP UT
M ODUL E
TS-ROM
SENSOR EXP ANSI ON
M ODUL E
TS-SEM
T O LOAD
DEVICES
# 21 - 24
# 25 - 28
# 33 - 36
# 37 - 40
T S-ROM BRIT EBOX
I/O MODULE
T S-CIM / T S-T GI
BRIT EBOX
T S-SEM BRIT EBOX
# 2
SENSOR EXPANSI ON
M ODUL E
TS-SEM
# 17 - 20 for TS-1001
# 13 - 16
# 29 - 32 for T S-2001
# 25 - 28
T S-SEM BRIT EBOX
# 1
TS-2001 TANK SENTINEL
®
STP
TS-RA1, or TS-RA2
Tank Overfill Alarm
(TS-RA2 shown)
TS-LLD
Line Leak Detector
TSP-HLS
Std High
Level
Sensor
TSP-DVS
Discrim.
Vapor
Monitoring
Well
BriteSensor
T S -2 0 0 1
T A NK SE N T INE L
TANK
SENTINEL
Console
TS-RK Alarm
Acknowledge unit
TSP-DIS Discriminating
Interstitial BriteSensor
TSP-LL2 Liquid
Level Probe
TSP-DTS
Discriminating
Turbine Sump
BriteSensor
TSP-DDS
Discriminating
Dispenser
Sump
BriteSensor
TSP-MWS Discriminating Ground
Water Monitoring Well BriteSensor
