Tank Sentinel Operator’s Guide
Special Keys ( Continued... )
Aborting a Tank or Line
Leak Test
An abort is used to cancel a
test... a test must be aborted
before a different type of leak
test can be started.
The display will show which test
(0.1 or 0.2 GPH) was aborted
once it has been chosen.
After a Tank or Line test is aborted
it is removed from the current-
running, abort-test display as
shown to the left
(in this case,
Tank 2 does not appear because
the test was aborted).
L
Y
TEST
0
1) Press the
TEST
key and then the
M3
key (above).
2) Press the
UP
or
DOWN
key to show all Leak
Tests that can be aborted (below)
3) Press a
menu
key under your selection to choose
the Tank or Line test to abort (below)
SELECT LEAK TEST OPTION
STATUS
START
ABORT
M1
M2
M3
M4
LEFT
RIGHT
SELECT TANK TO ABORT
TANK 1
TANK 2
ALL TANKS
M1
M2
M3
M4
LEFT
RIGHT
0.2 GPH TANK TEST ABORTED
M1
M2
M3
M4
LEFT
RIGHT
SELECT TANK TO ABORT
TANK 1
ALL TANKS
M1
M2
M3
M4
LEFT
RIGHT
