Tank Sentinel Operator’s Guide
Product & Tank Related Keys ( C
ONTINUED
... )
TANK
shows the PRODUCT name, the GROSS product-volume, NET product-volume
(which is temperature-compensated), WTR VOL (water volume), ULLAGE (gross volume
that could be added to fill the tank), actual product LEVEL, product TEMP (temperature),
WTR LVL (water level), and PERCENT full (capacity) values of the selected tank.
Ullage shows the
gross volume
that could be added to fill a tank without overfilling it
(to 95 % full / capacity).
Displays the actual
water level
in each tank. Press the TANK key to display both
WTR VOL (water volume) and WTR LVL (water level).
Menu Related Keys
The
CANCEL
key (upper right key) has many uses. Press
CANCEL
to:
•
cancel a menu choice (before the
ENTER
key is pressed)
•
return to default status display
•
exit out of and to return to a previous upper level menu or parent menu
•
cancel an input (before the
ENTER
key is pressed)
The
UP
key is used to travel up through a menu.
UP
must be pressed repeatedly (it will not scroll through a menu if it’s held-down).
The
DOWN
key is used to travel down through a menu.
Press
DOWN
when a menu is first accessed or entered. The
DOWN
key must also
be pressed repeatedly (it will not scroll through a menu if it’s held-down).
Press
DOWN
for other tanks.
WATER
TANK 1
TANK 2
TANK 3
TANK 4
INCHES
1.8
1.6
1.5
1.0
F
S
WATER
6
CANCEL
G
T
UP
+
/ –
K
X
DOWN
SPACE
Press
DOWN
for other tanks.
ULLAGE
TANK 1
TANK 2
TANK 3
TANK 4
GALLONS 2020
1020
383
220
E
R
ULLAGE
5
Press
DOWN
for other tanks &
Press a menu key to select a tank
Press
DOWN
to see additional tank
data ...(product level, temperature,
water level, and percent full)
D
Q
TANK
4
SELECT TANK
TANK 1
TANK 2
TANK 3
TANK 4
REGULAR
GROSS
NET
WTR VOL
ULLAGE
TANK 1
22080
21855
93.3
2020
REGULAR
LEVEL
TEMP
WTR LVL
PERCENT
TANK 1
98.25
67.8F
1.8
93.5
