Extron • System 8/10 P

LUS

• User’s Manual

RS-232 Programming Guide

Command and Response

A-4

Command/Response Table

Command

Response String

Command

String

Hex

Switcher to Host

Description; etc.

x!

* 21

Cx

(x is the channel #, 1 - 154)

Select Channel (See page A-2)

x$

* 24

Ax

(x is the audio channel #, 1 - 154)

Character following Command channel

x&

* 26

Vx

(x is the video channel #, 1 - 154)

number is a delimiter. It defines end of

x@

* 40

Cx

(x is the channel #, 1 - 154

Command string and further defines

* a channel number of up to 3 digits

the Select Channel command.

B

42

Blk·1

Turn Switcher RGB Mute ON

b

62

Blk·Ø

Turn Switcher RGB Mute OFF

c

63

(Same command as C below)

Request Projector Configuration

C

43

CONFIGURED·FOR·AMPRO··(POWER·UP····

This is an example response and may vary depending on the internal setting for the projector type.

i

69

(Same command as

I

below)

Information Request

I

49

Vx

1

·Ax

2

·Tx

3

·Px

4

·Sx

5

·Zx

6

·Rx

7

·QSCx

8

.x

9

x

10

·QPCx

11

.x

12

x

13

·Mx

14

V - Video (x

1

= channel # 1 to 154; if Ø = Sys power is off)

A - Audio (x

2

= channel # 1 to 154; if Ø = Sys power is off)

T - Video Type. (x

3

= 1 if RGBS, 2 if RGsB, 3 if Composite video, 4 if S-Video)

P - Display Power status. (x

4

= Ø power is off; 1 = on.)

S - Display Mute status. (x

5

= Ø mute is off; 1 = on.)

Z - Switcher Mute (x

6

= Ø, mute is off; 1 = on.)

R - Switcher RGB Mute status. (x

7

= Ø, mute is off; 1 = on.)

QSC - Switcher Comm software version # (3 digits x

8

.x

9

x

10

)

QPC - Projector Comm software version # (3 digits x

11

.x

12

x

13

)

M - Maximum channel available (x

14

= 8 - 154)

An example of a response to the I/i command:

V3·A3·T2·P0·S0·Z1·R1·QSC1.10·QPC1.09·M8

n

6E

(Same command as N below)

Request Part Number

N

4E

N60-107-01

(this is just an example response and may vary)

o

6F

(Same command as O below)

Toggle Display Power

O

4F

PR·1

Display power is ON, was off

PW·1

Please wait, Initializing

PW·E

Please wait, End

PR·Ø

Display power is OFF, was on

q

71

(Same command as Q below)

Query (See QSC & QPC above.)

Q

51

QSCx.xx

As an example:

QSC1.10

x.xx = Switcher Comm software version

QPCy.yy

As an example:

QPC1.09

y.yy = Projector Comm software version

r

72

(Same command as R below)

Toggle Switcher RGB Mute

R

52

BLK·1

Switcher RGB Mute ON, was off

BLK·Ø

Switcher RGB Mute OFF, was on

s

73

(Same command as S below)

Toggle Display Mute

S

53

MUT·1

Display Mute is ON, was OFF

MUT·Ø

Display Mute is OFF, was ON

x

78

(Same command as X below)

Toggle Executive Mode

X

58

UNLOCKED·FRONT·PANEL

If currently in Executive Mode

LOCKED·OUT·FRONT·PANEL

If not in Executive Mode

z

7A

(Same command as Z below)

Toggle Switcher Audio Mute

Z

5A

AMUT·1

Switcher Audio Mute is ON, was off

AMUT·Ø

Switcher Audio Mute is OFF, was on

[

5B

PR·1

Turn Display Power ON

PW·1

Please wait, initializing

PW·E

Please wait, END

]

5D

PR·0

Turn Display Power OFF

(

28

MUT·1

Turn display mute ON

)

29

MUT·Ø

Turn display mute OFF

+

2B

AMUT·1

Turn Switcher Audio Mute ON

-

2D

AMUT·Ø

Turn Switcher Audio Mute OFF

Error Response Codes

EØ1

Invalid Channel Number

EØ2

Slave Communication Error

EØ3

Projector is Powered OFF

EØ4

Projector Communication Error
