Extron • System 8/10 P

LUS

• User’s Manual

Introduction to System 8/10 P

LUS

Features

1-2

The system switcher can be controlled by the front panel switches, through its
manual remote connector (using E

XTRON

or third-party remote control devices), or

from a Host through an RS-232 connector. To address large installations with
more than 10 inputs, the switchers can be looped for a total of up to 154 inputs
(17 switchers). Features like Video Loop Back (VLB) make this switcher
adaptable to most application requirements.

Standard Features

Audio-follow switching

Audio Breakaway (RS-232 only)

Balanced audio inputs and outputs

Audio Mute button

Bandwidth of 300 MHz

Eight (System 8) or ten (System 10) inputs (expandable when looped)

Video inputs terminated at 75

(when not selected)

Dual microprocessor control

Projector power button

Projector video mute

Switcher RGB mute

Triple-Action Switching™ (RGB delay)

Contact closure and Tally remote control

RS-232 remote control

Video Loop Back

UL approved and CE compliant

Universal inputs

Universal projector control

Universal Projector Control

The System Switchers are compatible with many major brands of digital control
projectors on the market including:

Ampro

NEC/Runco

Barco

Panasonic

Digital Projection

Sanyo

Eiki

Seleco

Epson

Sharp

Electrohome

Sony

Hughes/JVC

Toshiba

InFocus

Zenith

Mitsubishi

If your projector manufacturer is not included in the above list, please contact
your Extron representattive.

The System 8/10 P

LUS

switchers are factory preset for the projector brand of

your choice, but can quickly and easily be reconfigured in the field for any other
compatible brand. Projector control from the switcher includes video muting and
turning projector power on/off. For some projectors, the projector’s remote
control device can be used to control the System 8/10 P

LUS

switcher as well.

Universal Inputs

All video and audio formats are supported with five BNC and 6-pin Phoenix®
connectors per input channel.
