Extron • System 8/10 P LUS • User’s Manual
RS-232 Programming Guide
A-3
Command/Response Table
The Command/Response table lists commands, responses and data characters
recognized by the System 8/10 P
LUS . The Command string (string = one or more
characters) in the left hand column of the table is defined in the right hand
column (both in Bold print). The Command string is shown as ASCII characters
and their hexadecimal (Hex) equivalent.
The Response string consists of one or more characters defining a function
followed by one or more characters defining the status of that function. A
carriage return followed by a line feed
(↵
= CR/LF = ØDh ØAh) defines the end of
the Response string. Possible error responses, EØ1 - EØ4 and EØ6, are shown at
the bottom of the table.
In a basic configuration (no master/slave looping), the Channel Select command
selects one of eight or ten inputs. However, in a more complex looping
configuration, it is possible to have up to 154 inputs.
Example:
A Channel Select command string for Input 154 could be:
154!
The Response string will be:
↵
C154
↵
The following page shows a list of System 8/10 P
LUS
commands or command
strings and their responses. Page A-5 shows a list of the same codes in numeric
order.
Command and Response
